Combined pH-Cond-TDS-salinity meter
Soil Lab
- Combined pH-cum-TDS-Salinity, Temperature meter,
Model-Hanna HI5521
- Use: To find the salinity and pH of soil
|
|
Dynamic cone penetration test
Soil Lab
- Pavement Dynamic Cone Penetrometer
- Use: To find the field CBR
|
|
Fall Cone Penetrometer
Soil Lab
- Digital type soil and bitumen penetration tester
- Use: To find the liquid limit of soil and
penetration value of bitumen
|
|
Triaxial Shear Test
Soil Lab
- Triaxial Cell (Universal), Load Cell (25kN),
Load Frame (100kN) & vertical clearance 800mm &
HC -325mm. Compressor-10kg/cm2,
vacuum pump & small cell, LVDT,
Data acquisition unit,
PR sensor, control panel unit
- Use: To find the shear strength of soil
|
|
Hydraulic extruder (Electrically operated)
Soil Lab
- Hydraulic extruder (motorised) adopter plates
and adopter for 38,50,75,100 and 150 mm tubes
- Use: To extrude the soil samples for testing
|
|
Unconfined Compression Test Setup
Soil Lab
- Unconfined Compression Tester with 2 kN proving ring
- and dial Gauge 0.01mm 25mm travel and
pair conical seating
- Use: To find the strength of soil
|
|
Consolidation Test Setup
Soil Lab
- Spacer (SS)-Fabricated at M/S Steel Industries
(60mm dia for consolidation cell)
- Use: To find the settlement of soil
|
|
Permeability Test Setup
Soil Lab
- Permeability Apparatus and overhead tank
- Use: To find the permeability of soil
|
|
Direct Shear Apparatus
Soil Lab
- Direct Shear Apparatus
- 2 KN with dial gauge and compression
Tester proving ring 2KN with dial gauge.
- Use: To find the strength of soil
|
|
Mechanical sieve shaker (motorized) with soil sieves
Soil Lab
- Set of soil sieves ,200mm diameter, brass frame
of sieve sizes 4075, 2.36,2.00,1.18,1.00mm,
600, 425, 300-, 150-, 90- and 75-micron
sieves with pan and lid.
- Mechanical sieve shaker, motorised with built
in timer for above (Sl.No.4)
- Use: For classification of soil
|
|
Automatic motorized universal compactor with Light and heavy compaction moulds
Soil Lab
- Automatic (motorised) universal Compactor for
both IS light and Heavy Compaction
- Compaction test equipment complete with
accessories (mould with base plate, collar etc.)
rammer for (a) IS light compaction and (b)IS
heavy Compaction,
as per IS 2720 parts 7 and 8
- Use: For soil compaction
|
|
CBR test equipment with CBR moulds
Soil Lab
- CBR Test equipment complete with standard CBR mould (16)
with base plate and collar rammer spacer disc surcharge weights
tripod and dial gauge for measurement of swell motorised loading
frame of capacity 5 tonnes with providing
ring and load dial, l oading plunger, penetration
measuring dial gauge etc. complete for carrying out CBR test.
- Use: To find the CBR value of soil for pavement design
|
|
Other basic equipments
Soil Lab
- Field density by core cutter method and sand replacement method
- Atterberg limit test apparatus
- Hydrometer, Pycnometer
- Post hole auger
- Use: to carry out tests in accordance with IS: 2720 – 1985
|
|
