Dynamic Shear Rheometer

Bitumen Lab
  • SmartPave 102e modular compact rheometer with
    Measuring plate pp25 d;25mm and Measuring
    plate pp08 d;8 mm.
  • Use: To find the rheological properties of the binder.



Distillation assembly

Bitumen Lab
  • Distillation system with heating mantle, 250ml flask
    wide mount with cork, thermometer, double jacked burette,
    400mm big condenser, 250mL reservoir flask,
    burette stand with three jaw clamp (2 sets) and PVC tube-1m
  • Use: For facilitating the separation of substances from
    a liquid mixture through boiling and condensation.

Brookfield Viscometer

Bitumen Lab
  • DV2 THA Brookfield Viscometer
  • Use: For measuring the viscosity of bituminous
    binders at different temperatures.

Ductility testing machine

Bitumen Lab
  • Ductility testing machine, electrically operated with
    thermostatically controlled water bath, heating element,
  • and thermometer.
  • Ductility and Elastic recovery test apparatus –
    set of three Briquettes.
  • Use: To determine the ductility of bituminous
    materials by measuring the breaking elongation.

Other Basic equipment

Bitumen Lab
  • Flash & fire point Test Apparatus
  • Penetration test equipment
  • Softening point test – Ring
  • Standard Tar Viscometer
  • Motorized centrifuge extractor
  • Use: Characterisation of binders in
    accordance with IS 73-2013
