Laboratories

NATPAC has well-furnished laboratories specializing in highway, traffic, and environmental engineering representing the vanguard of infrastructure innovation. These laboratories serve as crucibles for research, development, and practical application, fostering a synergistic approach towards enhancing infrastructure while promoting sustainability. Each discipline brings unique perspectives and methodologies, creating a holistic approach towards infrastructure development and management.


Highway Engineering Laboratory
Environment Engineering Laboratory
Traffic Engineering Laboratory
Survey Laboratory

Traffic Engineering Laboratory

Dynamic Speed Display Board

  • Displays speed of approaching vehicles in real time
  • Use: Measures the speed of approaching vehicles and displays the vehicle’s actual speed to drivers on a digital display

V Box mini module

  • General-purpose input/output module
  • Use: General-purpose input/output module to collect data such as temperature, RPM, wheel speed, fuel flow, throttle angles and pedal forces which can be measured along with the VBOX GPS data

Accessory sensor modules and inertia measurement unit

  • Basic sensor module for field measurements
  • Use: To find the dynamic flow characteristics of vehicle maneuvering

The Infra-Red Traffic Logger (TIRTL)

  • The Infra-Red Traffic Logger
  • Use: It is a multi-purpose traffic sensor that can be used as a traffic counter,speed sensor, red light camera sensor, heavy vehicle tracker, over height vehicle sensor, rail crossing sensor and network management system.

Video V Box Pro 10 Hz

  • Combines a 10 Hz VBOX GPS data logger with a 2 or 4 camera video system
  • Use: To determine the vehicular specific movement attributes

Sony Handycam with accessories (4 No:s)

  • Record video traffic data
  • Use: To record long duration traffic movement videos

Radar gun (2nos)

  • Transmits a narrow beam of radio-frequency energy which is reflected back to the gun after bouncing off from vehicles
  • Use: Device used to measure the speed of moving vehicles

Leica Disto meter (7nos)

  • Distance measurement based on the phase measurement principle
  • Use: To measure distances precisely and reliably at the touch of a button

Garmin GPS ETREX 22x (12 nos)

  • GPS receiver calculates its distance from four or more GPS satellites by trilateration to figure out exact location
  • Use: To determine a user’s exact location

Survey Laboratory

Electronic Total Station

Field Survey Equipment
  • A total station consists of a theodolite with a built-in distance meter (distancer) for measuring angles and distances at the same time.
  • Use: To measure both vertical and horizontal angles and the slope distance from the instrument to a particular point, and an on-board computer to collect data and perform triangulation calculations

DGPS Leica Viva

Survey Lab
  • Leica Viva Model GS14 DGPS GNSS Receiver
  • Use: To provide complete geospatial positioning solutions. These state-of-the-art devices are designed to provide precise and accurate location data for various applications, such as surveying, mapping, and construction.

Auto Levelling Equipment & Accessories

Field Survey Equipment
  • Model Leica NA 724
  • Use: To establish or check points in the same horizontal plane and to measure height differences as well as to transfer, measure, and fix the heights of known objects or markers.

Flow probe

Field Survey Equipment
  • The Flow Probe is a water flow meter which incorporates true velocity averaging for the most accurate flow measurements.
  • Use: To measure water velocity in rivers, streams and canals.

Leica Disto meter (7nos)

Traffic Engg. Lab
  • Distance measurement based on the phase measurement principle
  • Use: To measure distances precisely and reliably at the touch of a button

Garmin GPS ETREX 22x (12 nos)

Traffic Engg. Lab
  • GPS receiver calculates its distance from four or more GPS satellites by trilateration to figure out exact location
  • Use: To determine a user’s exact location

AO Plotter Machine

Survey Lab
  • Canon Make, Model no. iPF771, Resolution:2400×1200 dpi
  • Use: To print large-scale technical drawings, designs, and high-quality graphics and images
